Bench Lathe, KY1440C
Specification of Bench Lathe,KY1440C |
|
Model No. |
KY1440C |
Swing over bed |
358mm |
Swing over support |
223mm |
Swing over gap |
502mm |
Center height |
179mm |
Distance between centers |
1000mm |
Bed width |
187mm |
Bed height |
290mm |
Motor output |
1.5kw or 3kw/220V |
Voltage |
220V or 380V or 415V |
Spindle bore |
38mm |
Cam lock system |
D1-4 |
Spindle speed |
8/70-2000r.p.m |
Spindle taper |
MT 5 |
Cross slide travel |
160mm |
Compound slide travel |
95mm |
Leadscrew diameter |
22mm |
Feed rod diameter |
19mm |
Cutting tool(Max. section) |
16mm×16mm |
Imperial thread |
4-56T.P.I |
Metric thread |
0.4-7mm |
Longitudinal feed |
0.052-1.392mm/rev |
Cross-feed |
0.014-0.380mm/rev |
Tailstock quill diameter & taper |
32mm NO.3 |
Weight (Approx.) |
1000m |
Net weight/Gross weight |
505KG/595KG |
Packing size(cm)/With stands |
168×76×78/168×76×152 193×76×78/193×76×152 |
Standard Accessories for Bench Lathe, KY1440C |
|
Splash guard |
1pc |
Chip tray |
1pc |
3-jaw chuck |
1set |
Toolbox & tools |
1set |
Optional Accessories for Bench lathe, KY1440C |
|
4-jaw chuck(125mm) |
1set |
Backplate |
1pc |
Working lamp |
1pc |
Follow rest |
1pc |
Steady rest |
1pc |
Face plate(240mm) |
1pc |
Live center MT2 |
1pc |
Collet holder |
1set |
10mm turning tools(7pcs) |
1set |
Quick change tool post |
1set |
Stand |
1set |
Leadscrew cover |
1set |
As a professional supplier of bench lathe based in China, Kaiyun Machinery Company can provide not only high quality low-priced bench lathes, but also courteous services for our customers.
Our metalworking lathes, glassworking lathes, woodworking lathes, milling chucks, cutting tools and other products all enjoy one year warranty. Within this period, we will offer free maintenance, and ever return service to you.
Please contact us if you are in need of any of our products.
Bench Lathe,KY1440C Bench lathes, KY1440C are heavy duty machine tools widely used machinery used for cutting, knurling, drilling or sanding materials to create a new object.
